Container Growing Greenhouse - CONTAINER FARM: A NEW TYPE OF AGRICULTURE

We use 40HC refrigerated container with a good insulation. It is a closed growing system which enables a farmer (agrotechnician) to achieve constant production of vegetables all year around. The facility utilizes artificial control of light, temperature, moisture, and carbon dioxide concentrations.

Plant factories can produce vegetables about two to four times faster than typical outdoor planting.

Organic crops grown are healthier and do not use pesticides.

The plant factory can be moved to facilitate the transportation of vegetables

We are looking for representative worldwide.

Container Greenhouse
1、40RF（inner size:2.3m2.6m11.9m），growing area 2.3m10.5m，control area 2.3m1.5m 2、2 sets growing bed with the width of 800mm or 850mm 3、container equipped with intelligent control system、growing system，irrigation system， growing lighting system，air-condition system，fresh air circulation system，CO2 system etc.
NO.	name		specification
1	container		40RF insulated container
2	floor		1.5mm PVC plastic flooring; Wear-resistant and waterproof
3	growing system	growing bed	support frame, net
		growing pot	PE pot
		drainage gutter	PE drainage gutter
4	fertilizer and irrigation system	pump	Constant pressure water pump
		irrigation pipe	Φ20 PE pipe
		water dropper	4L/h
		drop arrow	2L/h, 2 pics/pot
		fertilizer machine	4 channels,peristaltic pumps injector
		fertilizer tank	food grade PP board,10L
		irrigation tank	food grade PP board,300L
		EC sensor	220V.3.2-inch display screen， 0.2-200.0US/CM
		PH sensor	220V.3.2-inch display screen， 0-14PH
5	growing lighting system	light	200W,LED special for cannabis
5	growing lighting system	jacking system	motor, driving system
6	illuminating system	control area	220V,20W,white light
6	illuminating system	growing area	220V,20W,white light
7	fresh air circulation system	fresh air machine	air exchange function and heat recovery function
		circulation fan	220V,30W,200m³/h
		air pipe	PVC pipe air outlet and return air inlet
8	air conditioning system	air conditioner	Cooling/Heating Refrigeran: R410a Power: 3HP Refrigerator Power:2350W Heating power:2800W Circulating Air Volume: 1200m³/h.
9	growth blowing system	fan	3 speed regualtion and shaking function
10	intelligent control system	intelligent control box	10 inches touch screen, manual and automatic control, PLC control system, online control function Siemens PLC controller Schneider electrical accessories
11	CO2 sytems		8L CO2 tank solenoid valve Pressure reducing valve
12	sensors	indoor air temperature, humidity and CO2 integrated sensor	LED display, -40 to 125℃, 0-100%RH. RS485 output
		soil temperature and humidity sensor	24V,0.4W,0-5000PPM measuring range:-40℃～+80℃ 0RH%-100RH%
		illumination intensity	0-200000 LUX precision: ±7%(25℃) RS485 output response time:0.1s
		Weather station	air temperature, humidity and CO2
13	other accessories		cable, cabling channel,conduit,pvc pipe, valve etc.
